Technical parameter
- Die cutting speed: 20-300 times/min
- Max. Unwind diameter: 600mm
- Max. Rewind diameter: 600mm
- Max. Web width: 350mm
- Max. Die cutting width: 350mm
- Max. Die cutting length: 350mm
- Position accuracy: 0.1mm
- Power: 8kw
- Voltage: 380V/50 HZ . 3Phase
- Overall dimension(L*W*H): around 2900*1160*1800mm
- Machine weight: around 2000kg
- PLC with touch screen: 1 set
- The machine is automatic paper feeder, web guide by sensor, color mark sensor, die cutter, waster wrapping, cutter device, automatic rewinder.
- Option: laminator, hot stamping function
Part Brand List
|
Item |
Brand |
Country |
|
Servo motor |
INOVANCE |
CHINA |
|
Engine controller |
INOVANCE |
CHINA |
|
Paper feeding motor |
INOVANCE |
CHINA |
|
Rewinding engine |
DC motor |
CHINA |
|
Controls (set) |
INOVANCE |
CHINA |
|
PLC |
INOVANCE |
CHINA |
|
Touchscreen |
Kunlun |
CHINA |
|
Speed transductor |
Shilin |
Taiwan, China |
|
Power switch |
Chengtai |
China |
|
Web guide photoelectric switch |
FuTai |
Taiwan, China |
|
Counting photoelectric switch |
BAIDELI |
China |
|
Main engine |
Y90s-4 |
China |
|
Feeding engine |
DC motor |
China |
|
Other electric components |
Chengtai |
China |
|
Contactor |
Schneider |
Japan |
|
Panel buttons |
Chengtai |
China |
FAQ
Q: What is the MQ-350 flatbed die cutting machine used for?
A: The MQ-350 is used for precision die cutting of roll-to-roll label materials, including self-adhesive labels, film labels, and specialty packaging materials. It can also perform laminating, waste stripping, slitting, and rewinding.
Q: What is the maximum web width of MQ-350?
A: Max web width: 320–350 mm (depending on configuration)
Q: What is the die cutting speed?
A: Typical speed: 20–220 cycles/min
Some servo high-speed versions can reach 300 cycles/min
Q: What is the cutting accuracy?
A: Standard accuracy: ±0.1 mm
High-end servo systems can achieve very stable registration performance
Q: What materials can MQ-350 process?
A: Common materials include:
Self-adhesive paper labels
PP / PET film labels
PVC labels
Laser anti-counterfeiting labels
Laminated label materials
Q: What is the maximum die cutting area?
A: Typical cutting area: 300 × 300 mm
Q: What is the maximum unwinding diameter?
A: Usually 500 mm (some configurations up to 600–800 mm)
Q: What is the maximum rewinding diameter?
A: Typically 500–600 mm
Q: What functions does the machine integrate?
A: MQ-350 usually supports:
Die cutting
Laminating
Waste removal (matrix stripping)
Slitting
Rewinding
Optional hot stamping / punching
Q: What type of die is used?
A: Flat steel rule die (wooden base die)
Custom-made according to label design
Q: What is the difference between flatbed die cutting and rotary die cutting?
A: Flatbed (MQ-350): High precision, suitable for small/medium runs and complex shapes
Rotary: High speed, suitable for long-run continuous production
Q: Why does MQ-350 use flatbed structure?
A: Because it provides:
Higher cutting pressure
Better precision for complex shapes
Strong adaptability to different materials
Q: What is the control system?
A: PLC control system
Touch screen HMI
Servo motor-driven feeding system
Q: What causes poor cutting quality?
A: Common reasons:
Dull or damaged die
Incorrect pressure setting
Poor registration alignment
Material stretching or instability
Incorrect feeding tension
Q: Why does registration drift happen?
A: Possible causes:
Servo calibration error
Material expansion/shrinkage
Sensor misalignment
Inconsistent tension control
Q: Can MQ-350 handle transparent film?
A: Yes, but requires:
High-sensitivity photoelectric sensors
Proper registration marks
Stable tension control system
